CLIP 3D Printing Technology: Objects Created in Liquid Resin

Linda Crampton taught science and information technology to high school students for many years. She enjoys learning about new technology.

The TED conference is held in the Vancouver Convention Centre at Canada Place.

The TED conference is held in the Vancouver Convention Centre at Canada Place.

A New Method of 3D Printing

A new and impressive method of 3D printing was introduced at the TED 2015 conference in Vancouver. It's now available commercially and is continuing to improve. The technology uses ultraviolet light and oxygen to create an object from a pool of liquid resin. As shown in the videos below, the object appears to "grow" from the liquid, reminiscent of the creation of the T1000 from the Terminator 2 movie. In fact, the CEO of the company that created the technology says that he was inspired by this movie.

The new printing method is known as CLIP, which stands for Continuous Liquid Interface Production. CLIP enables strong, functional, and attractive objects to be printed rapidly in an all-in-one process. In other 3D printing methods, a medium is deposited in layers in order to gradually build an object. The process is known as additive manufacturing.

Printing an object by additive manufacturing can be a time-consuming process, taking hours or even days to complete. In addition, because the object is made of layers that are fused together, the final product sometimes lacks strength. The layers may be visible in the final product, giving the object a banded appearance. CLIP can overcome these problems.

Printing a Lattice Shape With CLIP Technology (7X Speed)

The Carbon Company

The CLIP technology belongs to a company known as Carbon, which is based in Redwood City in California. The company was formerly called Carbon3D and still has the official name of Carbon3D, Inc. Based on the staff descriptions on the company's website, Carbon is run by some highly qualified and experienced people. The company has been in operation since 2013 but kept its endeavours secret—or at least unpublicized—until 2015.

The CEO of the company is Joseph DeSimone. He's on leave from his position as Chancellor's Eminent Professor of Chemistry at the University of North Carolina at Chapel Hill and from his other academic positions. He's said to be very knowledgeable about polymers. His team consists of chemists, engineers, computer scientists, and business people.

Chemistry, engineering, and computer science are involved in a CLIP printer's action. The object is created by starting and stopping chemical reactions. The equipment that allows this to happen in an engineering feat. The instructions that "tell" the equipment what to do are provided by a computer program.

We think that popular 3D printing is actually misnamed - it's really just 2D printing over and over again.

— Joseph DeSimone, CEO of Carbon3D, Inc.

Printing a Mini Eiffel Tower in Six Minutes

Printer Structure and Basic Function

In CLIP technology, a build platform moves upwards, pulling a gradually-forming shape out of a container of liquid. The liquid is a resin that is curable by UV light. The term "curing" refers to the hardening of a liquid by the formation of polymers, or long chains of molecules, and the creation of cross-links (bonds) between the polymers. Curing is triggered by the addition of energy, such as ultraviolet light or heat, or by the addition of certain chemicals.

At the bottom of the container of liquid resin is a transparent membrane, or window, that is permeable to oxygen. Underneath the window is a projector that emits ultraviolet light. The Carbon company likens the window to a contact lens, since it allows both light and oxygen to pass through it and enter the resin.

The combination of ultraviolet light and oxygen allows a 3D object to be created. The UV light triggers polymerization and the creation of cross-links in the resin, which causes solidification. Oxygen has the opposite effect. It stops the formation of polymers in the liquid resin immediately above the window and prevents solidification in that region.

The TED conference in Vancouver usually takes place in the spring. In 2020, it has been postponed until July due to the COVID-19 situation.

The TED conference in Vancouver usually takes place in the spring. In 2020, it has been postponed until July due to the COVID-19 situation.

CLIP 3D Printing in More Detail

In a CLIP printer, a continuous sequence of cross sectional images from a 3D graphics model is projected into the resin. The images are sent in the form of UV light patterns.

A very thin layer of resin just above the window in the liquid resin container is rich in oxygen. The oxygen-rich layer doesn't polymerize as UV light passes through it and is referred to as the dead zone. The resin above the dead zone lacks oxygen and does polymerize when the light strikes it, forming a solid according to the shape of the projected UV image.

The solid is slowly pulled out of the liquid as it forms. The suction forces that are created by this movement cause more liquid to move into position below the object. This means that the object that is being printed can be much taller than the depth of the liquid.

Due to the oxygen-rich resin at the bottom of the container, there is always liquid below the solidifying object, so the object doesn't stick to the bottom of the container. In addition, the object is both created and pulled upwards continually and smoothly without any pauses. These factors help to prevent the formation of layers and bands in the finished product.

Once an object has been printed, it's baked in a forced-circulation oven. This triggers a new chemical reaction that strengthens the object. The process is known as thermal curing. The double curing process involved in CLIP printing technology is said to produce an engineering-grade material.

The Vancouver Convention Centre is located at Canada Place, which is located next to Burrard Inlet and a pier with a promenade.

The Vancouver Convention Centre is located at Canada Place, which is located next to Burrard Inlet and a pier with a promenade.

Joseph DeSimone and a New Printer

Potential Benefits of the New Technology

CLIP printing is 25X to 100X faster than previous techniques. (The process may eventually reach 1000X times faster than conventional 3D printing.) This is a highly significant increase. It should end a lot of the frustration created by the time needed to produce a three dimensional object. It should also greatly increase the number of applications for 3D printing, allowing custom built items to be printed whenever we need them.

In addition, the all-in-one printing method should create a stronger object, depending on the printing medium that's used. Printed parts have consistent properties and look much more like injection-molded parts than the usual 3D printed items. The new technology can also make flexible and rubbery objects. Carbon is involved in the mass printing of the 3D midsoles for the Adidas Futurecraft 4D shoe.

3D Printing the Midsole of the Adidas Futurecraft 4D Shoe

Current Printer Models

In April 2016, Carbon's first printer (the M1) became available commercially. The company currently provides L1, M2, and M2d models of the printer.

  • The L1 printer is intended for high-volume production and has a build volume ten times bigger than that of the M1.
  • The M2 has a build volume twice as big as that offered by the M1 and has a resolution of 75μm (75 micrometres). A micrometre is a millionth of a metre. In 3D printing, the smaller the resolution number, the better the appearance of the object.
  • The M2d has similar features to the M2 but a smaller build volume. It's intended to be an entry level printer for dental labs.

Some Possible Problems With the Technology

When the original printer was first announced, there were concerns about the limited types of print media that were available. The list of materials is expanding, however. They currently include an elastomer. Elastomers are elastic polymers, as their name implies. The materials that can be used in the printer currently include the following:

  • silicone
  • flexible polyurethane
  • rigid polyurethane
  • elastomeric polyurethane
  • cyanate ester
  • epoxy
  • urethane methacrylate
  • various dental materials

Another concern about the original technology was the size of the objects that could be printed and the time needed for printing. The existence of the L1 and M2 printers may be at least a partial solution for these problems. The fact that CLIP 3D technology is continuing to advance is encouraging.

The revolving globe in the Vancouver Convention Centre is an appropriate symbol for the new ideas presented at TED, including CLIP printing.

The revolving globe in the Vancouver Convention Centre is an appropriate symbol for the new ideas presented at TED, including CLIP printing.

The Present and Future for CLIP

Carbon says that its printers are being used by companies and institutions. The printers are professional models and aren't aimed at consumers. The current models are available on a subscription plan rather than a purchase one. Even so, a subscription is expensive and is only affordable by certain businesses. Even more money is required for the printer installation, a training period, and other necessities.

Joseph DeSimone predicts that the printers will eventually offer many benefits. In the future, doctors may be able to create stents of the correct size for a patient during an operation. (Stents are used to keep blood vessels open.) Dentists may be able to print tooth implants while a patient is sitting in a dentist's chair. Car parts and other manufactured goods may be produced rapidly whenever they're needed.

Many ideas in technology don't live up to their expectations and fizzle out. Others are successful and allow technology to take a leap forward, sometimes improving our lives significantly. The CLIP 3D printing technology may be one of the latter ideas. It will be very interesting to see if this is true.
